ENAVISION 150 Dual Metal 3D Printer

Dual Laser Technology: Up to 50% Faster Production

The ENAVISION 150 Dual Metal 3D Printer is designed to optimize production efficiency and precision, making it an ideal solution for areas such as dental, medical, rapid prototyping, research institutions, and customization. This advanced 3D printing system is equipped with dual-laser technology, enabling faster and more accurate production of complex metal parts.

With its dual-laser configuration, the ENAVISION 150 reduces build times by up to 50%, significantly increasing productivity while maintaining high quality and repeatability. This enhanced performance not only accelerates output but also lowers operational costs without compromising precision or reliability.

The printer offers a round base plate with a production area of Ø150 mm x 70 mm and features an adjustable layer height ranging from 20 to 100 μm. Powered by two 300-watt fiber lasers, the system delivers efficient and high-quality results. Its high-speed dual scanning systems further boost speed and accuracy, making it suitable for even the most complex applications.

Compact in design, measuring just 1120 x 820 x 1900 mm, the ENAVISION 150 Dual is space-efficient and perfect for labs or office production environments. Additionally, this versatile 3D printer combines high-end performance with a lower investment cost.

FASTER PRODUCTION

FASTER PRODUCTION

Increase manufacturing speed and efficiency with cutting-edge dual laser technology

USER-FRIENDLY INTERFACE

USER-FRIENDLY INTERFACE

Enjoy an intuitive control system that simplifies operation and reduces training time

VERSATILE MATERIAL COMPATIBILITY

VERSATILE MATERIAL COMPATIBILITY

Effectively work with a wide range of materials, including titanium, cobalt, steel, Inconel, and more.

SCALABLE PRODUCTION

SCALABLE PRODUCTION

Easily adapt production volumes to meet changing demands without sacrificing quality.

RAPID PROTOTYPING

RAPID PROTOTYPING

Accelerate product development with fast and efficient prototyping capabilities.

CUSTOMIZABLE SOLUTIONS

CUSTOMIZABLE SOLUTIONS

Tailor your designs to meet specific requirements with flexible and adaptable production.

CONTROL UNIT

CONTROL UNIT

The industrial control unit is thoughtfully designed with advanced engineering equipment and a sleek, user-friendly interface featuring a multi-touch screen, ensuring ease of use.

COOLING UNIT

COOLING UNIT

Thanks to its compact design, the highly efficient cooling unit covers a minimum area. There are 2 separate outputs for laser source (resonator) unit and optical system.

POWDER RECOATING SYSTEM

It is the system carrying the metal powders within the powder feeding chamber to the production chamber at any layer thickness.

Since it can be adjusted precisely, production will be moderately precise, too.

You can also optimize your production speed with its adjustable speed

ERMAKSAN OWN LASER RESONATOR

ERMAKSAN offers high-efficiency single-mode fiber laser technology developed SLM and SLS technology to our customers.

ROBUST DYNAMIC CONTROL

  • Advanced technology laser control and laser driver
  • Input / output units designed at industrial standards
  • Flexible design control on I/O
  • Control and tracking over Modbus
  • Closed circuit power control management
  • Superior error detection algorithm
  • Ultimately efficient laser driver
  • Real time control
ERMAKSAN LASER RESONATOR

Ermaksan Laser Resonator

SCAN SYSTEM (F-Theta Lens)

The scan system is equipped with an F-Theta lens, making it ideal for additive manufacturing applications and renowned for its extended lifespan. It boasts a rapid positioning speed of up to 5.0 meters per second and is compatible with the ENAVISION 120 and 165 series 3D printers.

F-Theta Lens Optical scanning system

Optical scanning system (S)

VACUUM CLEANER SYSTEM

Optical scanning system (S)

VACUUM CLEANER SYSTEM

This system combines a powder vacuum cleaner with a wet separator to effectively collect metal powder laden air into a liquid-filled collection tank. During this process, the metal powder mixes with both air and liquid. This system is particularly suitable for handling flammable and explosive powders and is mandatory when working with titanium and aluminum powders, ensuring safety and efficient powder recovery.

ANTI-STATIC EQUIPMENTS

According to the method determined for part production in additive manufacturing technology, the powder particle size used varies between 20 - 200 μm. The powder particle sizes are at micron levels, making it easier to mix the powders into the air. The use of protective equipment in order not to be affected by the powder in the air allows the operator to make a healthier and safer production.

Anti-Static carpet
Anti-Static carpet (0)
Operator headed protection system
Operator headed protection system (O)
Anti-Static gloves
Anti-Static gloves (O)
Anti-Statik önlük
Anti-Static uniform (O)

TECHNICAL SPECIFICATION

  • ENA VISION 150
  • PRODUCTION AREAØ 150 mm
  • PRODUCTION HEIGHT70 mm
  • ADJUSTABLE LAYER HEIGHT20-100 μm
  • LASER TYPEEON Fiber laser (Ermaksan)
  • LASER POWER2 X 300 W
  • SCANNING SYSTEMHigh Speed Scan Head with F-Theta Lens
  • SCANNING SYSTEM PIECE2 SET
  • SCANNING SPEED (up to)5 m/s
  • COOLING SYSTEMAir
  • BUILDING PLATFORM PREHEAT-
  • ELECTRICAL CONNECTION (VOLTAGE)230 V, 1 PH, 50/60 Hz
  • ELECTRICAL CONNECTION (CURRENT)l25 / 32 A
  • INERT GASArgon / Nitrogen
  • O2 LEVEL100-2000 ppm
  • OPERATING SYSTEMWindows 10
  • NETWORKEthernet / Ethercat / USB
  • CONTROL SYSTEMBeckhoff Industrial PC
  • PROCESSORIntel® Core™ i5
  • HMI15.6 in, touch operated
  • DATA PREPARATION SOFTWAREMaterialise Magics and Modules
  • DATA PROCESSING SOFTWAREErmaksan Build Processor
  • SUPPORTED FİLE TYPESSTL ,( 3MF, AMF, DAE, FBX, VRML … )
  • MACHINE LENGTH ( L )1120
  • MACHINE WIDTH ( W )820
  • MACHINE HEIGHT ( H )1900
  • MACHINE WEIGHT750
